APPLICATIONS: The lamps are suitable for general lighting applications in homes, shops and hotels; Widely used in areas, such as restaurant, bar, living room, corridor, reception, etc.
|
CODE
|
PD42A-6W-D | PD42A-10W-D | PD42B-6W-D | PD42B-10W-D | ||
|---|---|---|---|---|---|---|
|
Dimension(mm) |
Ø90*H165 |
Ø120*H195 |
Ø90*H1145 |
Ø120*H1175 |
||
|
Cutout(mm) |
- |
|||||
|
Watt(W) |
6W |
10W |
6W |
10W |
||
|
Input Voltage |
AC220-240V |
|||||
|
LED Module Input |
- |
|||||
|
Light Source |
SMD |
|||||
|
CCT(K) |
1-CCT: 3000K/4000K/5000K/5700K 2-CCT: 3000K+4000K |
|||||
|
CCT Selection DIP Switch |
YES |
|||||
|
Luminous Flux (lm) ±5% CRI80 |
1-CCT |
Non-DIM |
- |
|||
|
|
|
DIM |
500-550lm |
890-900 |
500-550 |
890-900 |
|
|
2-CCT |
Non-DIM |
- |
|||
|
|
|
DIM |
500-550lm |
890-900 |
500-550 |
890-900 |
|
Beam Angle(°) |
160 ° |
|||||
|
UGR |
- |
|||||
|
Dimming Option |
Triac |
|||||
|
Sensor |
NO |
|||||
|
Emergency |
NO |
|||||
|
Product weight(Kg) |
N.W/PC |
0.33 |
0.56 |
0.37 |
0.61 |
|
|
|
G.W/PC |
0.41 |
0.67 |
0.46 |
0.75 |
|
|
Package weight(Kg) |
N.W/CTN |
3.96 |
6.72 |
4.44 |
7.32 |
|
|
|
G.W/CTN |
5.68 |
9.29 |
6.14 |
9.79 |
|
|
Qty/CTN (PCS) |
12 |
12 |
12 |
12 |
||
|
Carton Size(mm) |
400*335*210 |
520*425*240 |
335*230*355 |
425*290*415 |
||
|
20GP(pcs) |
11520 |
6156 |
11808 |
6120 |
||
|
40HQ(pcs) |
27648 |
13800 |
27888 |
15120 |
||
